Name: 24V 60Mpa Digital Diffused Silicon Pressure Sensor
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK81MA
Price: 21.00 USD
Availability: InStock

Dom > produkty > Compact Pressure Sensor >

24V 60Mpa Digital Diffused Silicon Pressure Sensor

Digital Diffused Silicon Pressure Sensor

60Mpa Compact Pressure Sensor

24V Diffused Silicon Pressure Sensor

Miejsce pochodzenia:

Chiny

Nazwa handlowa:

WNK

Orzecznictwo:

Numer modelu:

WNK81MA

Skontaktuj się z nami

Poproś o wycenę

24V 60Mpa Digital Diffused Silicon Pressure Sensor

Product Details

Sygnał wyjściowy:

4-20 mA/0,5-4,5 V

Typ czujnika:

Rozproszony krzem

Zakres ciśnienia:

10Kpa-60Mpa

Zasilanie napięciem:

24 V prądu stałego

Dokładność:

0,5% FS 1% FS

Temperatura:

-40-85C

Typ ciśnienia:

Ciśnienie względne Ciśnienie absolutne Ciśnienie uszczelnienia

Złącze elektryczne:

DIN43650

Podkreślić:

Digital Diffused Silicon Pressure Sensor

60Mpa Compact Pressure Sensor

24V Diffused Silicon Pressure Sensor

Payment & Shipping Terms

Minimalne zamówienie

1 sztuka

Szczegóły pakowania

Opakowanie standardowe lub zgodnie z wymaganiami

Czas dostawy

5-8 dni roboczych dla normalnego zamówienia

Zasady płatności

T/T, Western Union, Paypal

Możliwość Supply

3000/miesiąc

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

Uzyskaj najlepszą cenę

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

Uzyskaj najlepszą cenę

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

Uzyskaj najlepszą cenę

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

Uzyskaj najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Product Description

4-20mA 0.5-4.5V Diffused Silicon Pressure Sensor With Digital Display

Product Description

Output signal	4-20mA/0.5-4.5V
Sensor Type	Diffused Silicon
Pressure range	10Kpa-60Mpa
Voltage supply	24V DC
Accuracy	0.5%F.S 1%F.S
Temperature	-40-85C
Electrical Connector	DIN43650
Digital Display	Yes
Pressure Type	Gauge pressure Absolute pressure Seal pressure

Product Spec

24V 60Mpa Digital Diffused Silicon Pressure Sensor 0

24V 60Mpa Digital Diffused Silicon Pressure Sensor 1

FAQ

Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
