Name: Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

Dom > produkty > Compact Pressure Sensor >

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor Anti freezing

Miejsce pochodzenia:

HEFEI, CHINY

Nazwa handlowa:

WNK

Orzecznictwo:

CE, SGS, ISO9001

Numer modelu:

WNK80MA

Skontaktuj się z nami

Poproś o wycenę

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability

Product Details

Ciśnienie wejściowe:

0-1,6 MPa

Stabilność:

+/-0,5% FS, +/-1,0% FS (dla opcji)

Element czujnika:

Ceramiczny czujnik pojemnościowy

Stopień ochrony:

IP67, IP65

typ:

Miernik, absolutny

Wejście napięcia:

5VDC, 12VDC, 24VDC, 9-30V DC

Temperatura pracy:

-20C - 70C

Podkreślić:

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor Anti freezing

Payment & Shipping Terms

Minimalne zamówienie

5 sztuk

Cena

negotiable

Szczegóły pakowania

Opakowanie zdatne do transportu morskiego lub opakowanie zdatne do lotu

Czas dostawy

7-10 dni roboczych

Zasady płatności

T/T, Western Union, MoneyGram

Możliwość Supply

5000 szt. miesięcznie

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

Uzyskaj najlepszą cenę

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

Uzyskaj najlepszą cenę

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

Uzyskaj najlepszą cenę

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

Uzyskaj najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Product Description

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-freezing 0.5%FS Stability

Description

WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.

Technical Data

Applicable media	Liquid, Gas
Pressure range	0-1.6Mpa , 0-20Mpa, Customized
Pressure measurment	Gauge Pressure
Output	0.5-4.5V/4-20mA
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical), 1.0%FS ( for option)
Power supply	24VDC/12VDC/5VDC
Compensation temperature	-20~70ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet, Other
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.
