Name: WNK Air Pressure Sensors 4~20ma Low Pressure Differential For Wind And Dry Gas
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK808B
Price: 20.00 USD
Availability: InStock

Dom > produkty > Air Pressure Sensor >

WNK Air Pressure Sensors 4~20ma Low Pressure Differential For Wind And Dry Gas

piezoresistive pressure sensor

mini pressure sensor

Miejsce pochodzenia:

Anhui, Chiny

Nazwa handlowa:

WNK

Orzecznictwo:

ISO,Exia

Numer modelu:

WNK808B

Skontaktuj się z nami

Poproś o wycenę

WNK Air Pressure Sensors 4~20ma Low Pressure Differential For Wind And Dry Gas

Product Details

wejście ciśnieniowe:

-10Pa~100Pa, -100kPa~+100kPa

Sygnał wyjściowy:

4~20mA DC 2-przewodowe

Dokładność pomiaru:

0,2%, 0,5%

Zastosowanie:

Gaz, pomiar wiatru

Ochrona przed wnikaniem:

IP65

Moc:

24 V prądu stałego

Podkreślić:

piezoresistive pressure sensor

mini pressure sensor

Payment & Shipping Terms

Minimalne zamówienie

10 zestawów

Cena

negotiable

Szczegóły pakowania

Standardowe opakowanie kartonowe eksportowe

Czas dostawy

3 ~ 5 dni roboczych

Zasady płatności

T/T, Western Union, MoneyGram

Możliwość Supply

200 zestawów/dzień

Mini Gas Pressure Transmitter Air Pressure Transducer With Customized Electrical Connection

Uzyskaj najlepszą cenę

Wideo

High Accuracy Air Pressure Sensor Packard Connector For Water Tank

Uzyskaj najlepszą cenę

Wideo

Brass Cable Outlet Air Pressure Transducer Sensor 15mA Max Current

Uzyskaj najlepszą cenę

Wideo

0-2000 KPa Air Pressure Sensor Anti - Corrosion And Vibration Resistance

Uzyskaj najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Product Description

4~20ma Low Pressure Differential Air Pressure Sensors Pressure Transmitter For Wind And Dry Gas

WNK268 ( WNK808B ) Wind Pressure Sensor uses silicon pressure sensor element and aluminum alloy housing structure. Two pressure ports with M10 thread, and can be installed directly in the instrument chassis or connected through the pressure tube. Choose products millivolts, standard voltage, current, frequency signal, to install and easy to use, widely used in the field of wind pressure control of the boiler air supply, mine ventilation, electricity, coal industry.

Specifications

Pressure range	-100KPa……0~1KPa……100KPa
Overload capacity	150%
linearity	<±0.1%FS
Repetition	<±0.05%FS
Delay	<±0.05%FS
Input impedance	0.6~6KΩ
Compensation temperature	-10°C~+70°C
Working temperature	-40°C~+85°C
Insulation resistance	>100MΩ/50V
Insulating strength	>500MΩ/500V
Pressure connection	The pagodas head with M10 thread
Electrical connection	Cable or connectors
Medium	Liquid compatible with 316 stainless steel
Protection Grade	IP65
Explosion-proof Grade	ExiallCT5

Application

It is the best micro pressure measurement equipmenttextile for textile machinery,natural gas pipeline monitoring,dust removal system, HVAC,clean laboratory and medical equipment etc.
