Name: Model 268 Air Differential Air Pressure Transmitter for Wind / Dry Air
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK808B
Price: 20.00 USD
Availability: InStock

Dom > produkty > Air Pressure Sensor >

Model 268 Air Differential Air Pressure Transmitter for Wind / Dry Air

air pressure transmitter

mini pressure sensor

Miejsce pochodzenia:

Anhui, Chiny

Nazwa handlowa:

WNK

Orzecznictwo:

ISO,Exia

Numer modelu:

WNK808B

Skontaktuj się z nami

Poproś o wycenę

Model 268 Air Differential Air Pressure Transmitter for Wind / Dry Air

Product Details

Zakres:

-10Pa~100Pa, -100kPa~+100kPa

Wyjście:

4~20mA DC 2-przewodowe

Dokładność:

0,2%, 0,5%

Zastosowanie:

Gaz, pomiar wiatru

Klasa ochrony:

IP65

Wejście napięcia:

24 V prądu stałego

Podkreślić:

air pressure transmitter

mini pressure sensor

Payment & Shipping Terms

Minimalne zamówienie

10 zestawów

Cena

negotiable

Szczegóły pakowania

Standardowe opakowanie kartonowe eksportowe

Czas dostawy

3 ~ 5 dni roboczych

Zasady płatności

T/T, Western Union, MoneyGram

Możliwość Supply

200 zestawów/dzień

Mini Gas Pressure Transmitter Air Pressure Transducer With Customized Electrical Connection

Uzyskaj najlepszą cenę

Wideo

High Accuracy Air Pressure Sensor Packard Connector For Water Tank

Uzyskaj najlepszą cenę

Wideo

Brass Cable Outlet Air Pressure Transducer Sensor 15mA Max Current

Uzyskaj najlepszą cenę

Wideo

0-2000 KPa Air Pressure Sensor Anti - Corrosion And Vibration Resistance

Uzyskaj najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Product Description

Model 268 Air Differential Air Pressure Sensor Pressure Transmitter for Wind/Dry Air

WNK268 ( New Model WNK808B ) intelligent pressure transmitter is assembled with aluminum housing and stress isolation technology. Integrated structure design lead to compact layout. With intelligent compensation technology, it is suitable for wind pressure,wind speed & flow measurement. It is widely used in various industrial fields as well as intelligent building and other construction projects, such as power plant boiler primary air,secondary air measuring, mine ventilation,indoor ventilation, pressure of fan, air duct pressure, Metro wind pressure and environment wind pressure test.

Application

It is the best micro pressure measurement equipmenttextile for textile machinery,natural gas pipeline monitoring,dust removal system, HVAC,clean laboratory and medical equipment etc.

Specifications:

Applicable media	Gas, Air, Wind
Pressure Measurement	Gauge pressure, Differential pressure, Negative, Vacuum
Pressure range	-10Pa~100Pa, -100kPa~+100kPa
Accuracy	0.2%, 0.5%
Stability	0.5%F.S/Year
Maximum static pressure	100kpa
Max overload	250% of sensor range
Output signals	4~20mA 1-5V
Housing material	Aluminum14
Induct Pressure Connection:	M 8x1 female or Ø 8 dowel connection
Power Supply	EEX ia:10.5~30 V DC Non-explosion: 10.5~45V DC
Ambient temperature	-40~85℃
Compensation temperature	-10~70℃
Working temperature	-10~70℃
