Name: Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

Dom > produkty > Compact Pressure Sensor >

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input

electronic pressure sensor

precision pressure sensor

Compact Pressure Transmitter 100Kpa

Miejsce pochodzenia:

HEFEI, CHINY

Nazwa handlowa:

WNK

Orzecznictwo:

CE, SGS, ISO9001

Numer modelu:

WNK80MA

Skontaktuj się z nami

Poproś o wycenę

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input

Product Details

Wejście:

-100Kpa - 70Mpa

Wyjście cyfrowe:

I2C, SPI

Wyjście analogowe:

4-20mA, 0,5-4,5VDC

Złącze ciśnieniowe:

NPT1/8 G1/4 Dostosowane

Dokładność liniowa:

0,5% FS, 1,0% FS

Przeciążenie ciśnienia:

2-3 razy

Dowód:

IP67

Podkreślić:

electronic pressure sensor

precision pressure sensor

Compact Pressure Transmitter 100Kpa

Payment & Shipping Terms

Minimalne zamówienie

5 sztuk

Cena

negotiable

Szczegóły pakowania

Opakowanie zdatne do transportu morskiego lub opakowanie zdatne do lotu

Czas dostawy

7-10 dni roboczych

Zasady płatności

T/T, Western Union, MoneyGram

Możliwość Supply

5000 szt. miesięcznie

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

Uzyskaj najlepszą cenę

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

Uzyskaj najlepszą cenę

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

Uzyskaj najlepszą cenę

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

Uzyskaj najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Product Description

Digital Hydraulic Water Treatment Compact Pressure Sensor Pressure Transmitter

Description

WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. In addtion to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement

Specifications

Applicable media	Liquid, Gas
Pressure range	0-7kPa~350bar
Pressure measurment	Gauge Pressure, Absolute pressure, Sealing pressure
Output	4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical)
Power supply	24VDC/12VDC/5VDC/3.3V
Compensation temperature	-20~85ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel(inner core is 316 stainless steel)
Protection	IP65

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.
